Working Performance

Max. rated lifting capacity X working radius: 30,000 X 3.0 kg.m

Max. load moment of basic boom: 960kN.m

Max. load moment of max. length main boom: 660kN.m

Max. lifting height of main boom: 37.2m

Max. lifting height of jib: 46m

Dimensions

Overall dimensions (L X W X H): 13,600 X 2,610 X 3,600mm

Distance between outriggers (Longitudinal X transversal):6,700 X 6,300mm

Main boom length (completely retracted – completely extended): 10,700～35,000mm

Jib length: 8,000mm

Boom angle: -2°- 80°

Swing range: unlimited swing (Full range)

Working Speeds

Max. Hoist rope speed (main winch): 140m/min

Min. boom telescoping out time: 67s

Min. boom telescoping in time: 50s

Min. boom derricking up time: 35s

Min. boom derricking down time: 50s

Swing speed: 0-2.5 r/min

Hydraulic system	Rated working pressure	MPa	22
Rated working flow	L/min	300
Hydraulic oil tank capacity	L	580
Mass	Complete vehicle kerb mass	kg	28300
Front axle load	kg	14600
Rear axle load	kg	13700
Driving	Max. travel speed	km/h	45
Wheelbase	mm	3880
Treads (Front / rear)	mm	2214
Max. gradeability	%	51

For the new product, please check their official website for details:

https://en.zoomlion.com  (search the model online).

This product is made by Zoomlion, if you are looking for similar used cranes from other brands like Sany, XCMG, Liu Gong, ZPMC, Sunward, Konecranes, Liebherr, Demag, Terex, Tanano, Manitowoc, Cargotec, Palfinger, Sunward etc, please feel free to ask us any question related.
