Max. lifting capacity:  55 t

Max. lifting height:  45.6 m

The largest crane operating range, and the most optimal lifting performance in the industry.

Five-section U-shaped boom of large cross section with maximum length reaches up to 45m and jib of the length of 16 m.

The 7.5m transverse outrigger span with a fixed counterweight of 3.3t makes its lifting performance 5-10% higher than that of the products of same class.

Cummins ISLe series high pressure common rail large torque euro III engine of 340 horsepower is configured.

The combination of Fast 9-speed gearbox and double reduction axle features large speed ratio range, which meets the requirements of low gradeability speed and high traveling speed.

The max. traveling speed is 85km/h and max. gradeability is up to 46%.

Load sensitive valve compensation technology, with stable control.

Max. rated lifting capacity	55 t
Max. rated lifting torque of basic boom	2033 kN路m
Max. rated lifting torque of full extended	1192 kN路m
Max. lifting height of main boom	45.6 m
Max. lifting height of Jib	45.6+16.4 m
Overall net weight	43400 kg
Max. single rope speed	130 m/min
Time of telescoping boom	100 s
Time of elevating boom	45
Max. slewing speed	2.2 rpm
Max. travel speed	85 km/h
Gradeability	47%
Min. turning diameter	24 m
Dimensions (L x W x H)	13950x2800x3730 mm
Outrigger longitudinal span	5750 mm
Outrigger transverse span	Full:7500 / Half:5020 mm
Sections of boom	5
Length of main boom	45 m
Length of jib	16 m
Type	ISL9.5-340E51A
Engine Model	QSB6.7-C220
Rated power	251/164 kW
Max. rated torque	1500/949 N路m

For the new product, please check their official website for details:

http://www.liugonggroup.com ( search on their website )

This product is made by Liu Gong, if you are looking for similar used cranes from other brands like Sany, XCMG, Zoomlion, ZPMC, Sunward, Konecranes, Liebherr, Demag, Terex, Tanano, Manitowoc, Cargotec, Palfinger, Sunward etc, please feel free to ask us any question related.
